Mini but Large
NUX Flow Tune has a compact design with a large high-definition LCD display. Every one can
easily read the notes while standing on the stage. Perfect for live guitarists.
Easy to fit, easy to tune.

Flow in Tune
There are 3 display modes including a Strobo mode and 2 Arrow modes. The featured display is
vivid and looks like a flowing river! Simply flow in tune with your guitar.

Monitoring while Playing
NUX Flow Tune offers True Bypass, Buffered Bypass, as well as a Buffered Bypass Monitor mode
which can help you monitor the tuning even while you are playing.

TB (True Bypass): When the tuner is bypassed, the pedal is a True Bypass circuit that has no
influence on your output signal. When the tuner is activated and starts tuning, the output
will be muted.

BF (Buffered Bypass): When the tuner is bypassed, the output signal is driven by a Buffered
Bypass circuit. When the tuner is activated and starts tuning, the output will be muted.

BFM (Buffered Bypass Monitor): The signal is driven exactly as in the Buffered Bypass mode,
while the output remains unmuted no matter the tuner is activated or deactivated.

Fits Any Board
Compact size and steady weight, easy to fit the pedalboard with velcro.Besides that, the
specially-designed footswitch offers comfortable pressing feedback.

Features :

• Tuning range: A0 (27.5Hz) - C8 (4186Hz)
• Tuning modes: Chromatic, Guitar, Bass
• Display modes: Strobo Mode, Arrow Mode 1, Arrow Mode 2
• Bypass modes: True Bypass, Buffered Bypass, Buffered Bypass Monitor
• A4 calibration: 430Hz – 450Hz
• Tuning accuracy: 0.1 Cent
• Input impedance: 10M Ohm
• Output impedance: 1K Ohm
• Current draw: <100mA
• Weight: 197.4g
• Dimensions: 97.4mm x 43.5mm x 41.6mm
