Audio-Technica AT-LP5X Fully Manual Direct Drive Turntable ( ATLP5X / AT LP5X )

Audio-Technica AT-LP5X Fully Manual Direct Drive Turntable ( ATLP5X / AT LP5X )

Audio-Technica AT-LP5X Fully Manual Direct Drive Turntable ( ATLP5X / AT LP5X )

Building on Audio-Technica’s analogue heritage and over 50 years of Japanese audio design, the AT-LP5x features upgraded technology while keeping the contemporary style and acclaimed performance of its predecessor, the AT-LP5.

The LP5x retains the J-shaped tonearm, a design inspired by the classic Audio-Technica models of the 1960s and ’70s, and features a metallic gimbal suspension system and precision bearings to mitigate tracking errors. The tonearm also includes an adjustable counterweight and anti-skate control and comes fitted with a lightweight (9.3g) AT-HS6 headshell and the black AT-VM95E Dual Moving Magnet stereo cartridge.

Constructed of anti-vibration damping materials with heavy-mass metal chassis inserts, the AT-LP5x turntable has been designed to limit low-frequency acoustical feedback. Its precision-machined, die-cast aluminum platter is powered by a direct-drive, low-noise motor, ensuring stable, on-axis rotation at 33-1/3, 45 and 78 RPM. A 5 mm thick rubber-damping mat, which isolates from low frequency feedback while providing a highly stable surface for all LP formats, tops the platter.

The AT-LP5x features a built-in switchable MM/MC phono/line preamp that enables it to connect directly to a computer, home stereo, powered speakers and other components that have no dedicated turntable input. The selection of MM/MC cartridges allow for an easy upgrade to a moving coil with additional equipment. The turntable is also equipped with a USB output for direct connection to a computer.

• Direct-drive, low noise motor
• Fully manual operation with three speeds: 33-1/3, 45 and 78 RPM
• AT-VM95E Dual Moving Magnet stereo cartridge (black) with replaceable stylus
• Lightweight AT-HS6 headshell
• J-shaped tonearm, modeled after original Audio-Technica designs from the 1960s and ’70s, are engineered to minimize tracking errors
• Switchable MM/MC built-in pre-amplifier and line enables connection to components with or without a dedicated phono input
• Anti-resonance, die-cast aluminum platter
• Heavy rubber damping mat for improved low-frequency reproduction
• AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
• Elegant matte black finish
• Includes dual RCA (male) to dual RCA (male) stereo cable, 45 RPM adapter, USB cable
• Included dust cover and mounting hardware

Specifications

• Type : 3-speed, fully manual operation
• Motor : DC motor
• Drive Method : Direct Drive
• Speeds : 33-1/3 RPM, 45 RPM, 78 RPM
• Turntable : Platter Die-cast aluminum
• Starting Torque : >1.0 kgf.cm
• Braking System : Electronic brake
• Wow and Flutter : <0.2% WRMS (33 RPM) at 3 KHz
• Signal-to-Noise Ratio : >50 dB
• Output Level : PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec LINE 250 mV nominal at 1 kHz, 5 cm/sec
• Phono Pre-Amp Gain : 36 dB nominal, RIAA equalized MC: 56dB nominal, RIAA equalized
• USB Function : A/D, - 16 bit 44.1 kHz or 48 kHz USB selectable; Computer interface - USB 2.0 compliant Windows 7 or above, MAC OS X or above
• Power Supply Requirements : 100-240V AC, 50/60 Hz
• Dimensions : 450.0 mm (17.72") W x 352.0 mm (13.86")D x 157.0 mm (6.18")H
• Weight : 7.3 kg (16.1 lbs.)
