Behringer WING Rack – 48-Channel Rackmount Digital Mixer with Touchscreen & Network Audio Support

Behringer WING Rack – 48-Channel Rackmount Digital Mixer with Touchscreen & Network Audio Support

The Behringer WING RACK brings the powerful mixing architecture and intuitive workflow of the full-size WING console into a compact 4U rackmount format. Its adjustable front panel and 10.1" multi-touch display provide convenient hands-on control whether installed in a rack or used as part of a portable production system.

Equipped with 24 Midas PRO microphone preamps, extensive AES50 connectivity, 48-channel USB audio/MIDI and professional onboard processing, WING RACK is built for live sound, studio recording, broadcast and installed audio applications. Its flexible routing, stereo processing architecture and expansion options make it suitable for complex professional audio systems.

Features

• 24 Midas PRO microphone preamps for professional-quality audio capture
• 8 analog outputs for flexible signal routing
• Adjustable swivel front panel provides comfortable operation when rack-mounted
• 10.1" capacitive multi-touch TFT display with 1280 × 800 resolution
• Dedicated Custom Control section with 16 customizable layers
• 3 pre-configured channel control layers
• 8 buttons and 4 rotary encoders for mixing, transport and custom functions
• 3 AES50 ports supporting up to 144 input and output signals
• SuperMac CAT5 connectivity with ultra-low jitter and 6-sample latency
• Integrated 48 × 48 USB audio/MIDI interface
• Dual-SD card recorder/player supports up to 64 tracks
• 40 stereo input channels with 5 variable processing plug-in slots each
• 8 stereo auxiliary input channels
• 4 Main, 8 Matrix and 16 Aux stereo buses
• 16 true-stereo effects engines with 80+ processing algorithms
• Dedicated Gate, Dynamics and EQ processing slots on every channel
• 8 mute groups and 8 DCAs for convenient channel management
• Dual Ethernet ports with integrated network switch
• Optional Dante and Waves SoundGrid AoIP connectivity
• Rear expansion slot supports compatible Dante, WSG, MADI and other interface cards
• StageConnect Host interface supports up to 32 channels via a single XLR connection
• 4 additional headphone outputs for monitoring and IEM applications
• 4-channel GPIO for external control integration
• 5-pin MIDI In and Out for external equipment control and synchronization
• DAW remote control compatible with Mackie Control Universal (MCU)
• Supports Cubase, Ableton Live, Logic Pro, Nuendo, Pro Tools, Reaper and Studio One workflows
• Remote control and offline editing through WING-CoPilot, WING-Q and WING-Edit
• Compact 19" rackmount design with 4U form factor

Specifications

• Brand: Behringer
• Model: WING RACK
• Type: Rackmount Digital Mixing Engine
• Input Channels: 40 Stereo Channels
• Auxiliary Inputs: 8 Stereo Channels
• Buses: 4 Main / 8 Matrix / 16 Aux Stereo Buses
• Microphone Preamps: 24 × Midas PRO
• Analog Outputs: 8
• AES50 Ports: 3
• AES50 Capacity: Up to 144 Input / Output Signals
• USB Audio Interface: 48 × 48 Channels
• SD Recorder: Dual-SD, Up to 64 Tracks
• Effects Engines: 16 True-Stereo
• Effects Algorithms: 80+
• Mute Groups: 8
• DCAs: 8
• Display: 10.1" TFT LCD Capacitive Multi-Touch
• Display Resolution: 1280 × 800
• Ethernet Ports: 2
• StageConnect: Up to 32 Channels Bidirectional
• MIDI: 5-Pin MIDI In / Out
• GPIO: 4-Channel
• Frequency Response: 10 Hz–20 kHz @ 48 kHz, 0 to -1 dB
• Power Supply: Auto-Ranging 100–240V AC, 50/60 Hz
• Power Consumption: 130W
• Rack Size: 19", 4U
• Dimensions: 48.6 × 32.6 × 18.3 cm
• Weight: 9.44 kg
