EV Electro-Voice ZLX-15 G2 1000W 15" Passive Speaker - Each / Pair ( ZLX-15 / ZLX 15 )

EV Electro-Voice ZLX-15 G2 1000W 15" Passive Speaker -  Each /  Pair ( ZLX-15 / ZLX 15 )

The ZLX-15 G2 1000W 15  is part of the second‑generation lineup of Electo‑Voice’s acclaimed ZLX series. Step up to the best-in-class sound of the Electro-Voice ZLX-15. Experience robust lows and room-shaking volume, thanks to a 15" woofer and impressive power handling. And with 90° x 60° coverage, your entire audience is sure to enjoy excellent sound. Installing this passive speaker is a piece of cake — mount it on a pole, stack it on a subwoofer, or position it onstage for monitoring. The ZLX-15's patented split-baffle design yields superior driver time alignment, enhanced sonic impact, and increased intelligibility. And its road-ready construction and unique grip design make transportation easy.

Features

• 250W/1,000W passive speaker with 15" woofer and 1.5" high-frequency titanium compression driver
• 44Hz–20kHz frequency range and 126dB maximum SPL deliver immersive sound and room-filling volume
• 90° x 60° coverage ensures that everyone in your audience experiences top-shelf sound
• Mount it on a pole, stack it on a subwoofer, or position it onstage for monitoring
• Lightweight and unique grip design for easy transportation
• Rugged, road-ready construction

Specifications:

Audio Performance

• Frequency response (–3 dB): 48 Hz – 18,000 Hz

• Frequency range (–10 dB): 42 Hz – 20,000 Hz

• Maximum sound pressure level @ 1 m: 129 dB

• Coverage angle (Horizontal × Vertical): 90° × 60°

• Crossover frequency: 1.40 kHz

Power

• Power rating: 1000 W

• Power consumption: 100 – 240 V~, 50 – 60 Hz

Transducers

• LF transducer model: WECA2158

• LF transducer size: 15 in

• LF magnet material: Ferrite

• HF transducer model: DECA2516

• HF transducer type: Compression driver

• HF transducer size: 1.40 in

• HF magnet material: Ferrite

• HF diaphragm material: Titanium

Connectivity

• Input connectors:

  • (2) XLR/TRS combo jacks

  • (1) 1/4-inch TS Hi-Z input

Enclosure and Build

• Cabinet material: Polypropylene

• Grille material: Powder-coated steel

Dimensions

• Product dimensions (H × W × D):

  • 697.6 mm × 422.8 mm × 383.1 mm

  • 27.46 in × 16.65 in × 15.08 in

• Shipping dimensions (H × W × D):

  • 765 mm × 490 mm × 490 mm

  • 30.12 in × 19.29 in × 19.29 in

Weight

• Net weight: 16.78 kg / 37 lb

• Shipping weight: 19.64 kg / 43.30 lb
