Mackie Onyx12 12-channel Analog Mixer with Multi-Track USB

Mackie Onyx12 12-channel Analog Mixer with Multi-Track USB

The Mackie Onyx12 is a premium 12-channel USB mixer optimized for multitrack recording and live sound. Experience impeccable sound quality, a flexible FX engine and seamless workflow for your home recording or live shows.

Level-up your rig with a versatile 12-channel mixer designed by engineers who know that great sound lives in the details. Every element of the Mackie Onyx12 is geared towards recording at a professional level, from our award-winning Onyx preamps to the Perkins “British Style” EQs inspired by classic desks from the ‘60s and ‘70s.

FEATURES

• Classic Sound, Modern Performance

• Multitrack Recording via USB or SD card, up to 24-bit/96kHz

• Award-Winning Onyx Preamps for Pristine Audio

• Powerful FX Engine with Customizable Presets

• Studio Command Interface with Full-color LCD

• Bluetooth® Streaming

SPECIFICATIONS

• Type: Analog Mixer
• Channels: 12
• Computer Connectivity: USB, Bluetooth
• A/D Resolution: 24-bit/96kHz
• Inputs - Mic Preamps: 8 x XLR
• Phantom Power: Yes
• Inputs - Line: 14 x 1/4", 1 x 1/8"
• Outputs - Main: 2 x XLR (main), 2 x 1/4" (main), 2 x 1/4" (control room)
• Send/Return I/O: 1 x 1/4" (FX), 2 x 1/4" (mon)
• Inserts: 4 x 1/4"
• Headphones: 1 x 1/4"
• USB: 1 x Type B
• Bluetooth: Yes
• Other I/O: 1 x 1/4" (footswitch)
• EQ Bands: 4-band EQ
• Effects: Yes
• Storage: SD card slot
• Power Source: Standard IEC AC cable
• Height: 5.4"
• Width: 14.8"
• Depth: 14"
• Weight: 12.7 lbs.
