Specifications:
• Input jack (INPUT): For connecting a bass
• Volume adjustment (VOLUME): Used to adjust the volume of the whole machine
• IF Notch Switch (MID NOTCH SWITCH): Pressing this switch moves the middle frequency band, changing the timbre.
• Bass adjustment (BASS): Used to adjust the boost/cut amount in the bass range
• Low-midrange adjustment (LOW MID): Used to adjust the boost/cut amount in the low-mid range
• High-mid frequency adjustment (HIGH MID): Used to adjust the boost/cut amount in the high-mid range
• Treble adjustment (TREBLE): Used to adjust the boost/cut amount in the treble area
• Headphone output jack (PHONE): Used to connect headphones. The built-in speakers will be disconnected.
• Line-out jack (LINE OUT): Used to connect other recording equipment or power amplifiers.
• Music input jack (AUX): For music input
• Power Indicator: (POWER LED: Used to indicate the working status of the machine. The red light means that the amplifier is turned on.
• switch (POWER SWITCH): For power on
• Output Power:100Wpower supply:AC220V / 50HZ / AC110V / 60HZ
• Dimensions: (H x W x D): 430 x 420 x 230 (mm)
• Signal-to-Noise Ratio:≥70dB
• input resistance:＞1MΩ
• Speaker Impedance: 8Ω（12" speaker）
