Zoom MS-70CDR+ MultiStomp Guitar Effects Pedal ( MS-70CDR+ )

Zoom MS-70CDR+ MultiStomp Guitar Effects Pedal ( MS-70CDR+ )

The MS-70CDR+ gives musicians 149 spatial effects ranging from lush choruses to crystal-clear delays to atmospheric reverbs. This single stompbox can shape your tone and provide endless depth and textures.

FEATURES

• MS-70CDR+ on a pedalboard
• 140+ guitar and bass effects, including modulation, chorus, delay, and reverb
• Use up to 6 effects at the same time
• 100 Patch slots with 80 presets
• Analog circuit with minimal sound deterioration
• Single stompbox design
• Stereo input and output supports effects like stereo chorus and delays
• 4x Cross Key switches (MEMORY / SCROLL) for easy operation by foot
• Improved UI for easier navigation and control
• Color coded LCD backlight for selected effect category
• Runs on 2 AA batteries or AC Adapter

SPECIFICATIONS

• Maximum number of simultaneous effects: 6 effects
• User patch memories: 100
• Sampling frequency: 44.1 kHz
• A/D conversion: 24-bit 128× oversampling
• D/A conversion: 24-bit 128× oversampling
• Signal processing: 32-bit
• Frequency response: 20 Hz - 20 kHz (+0.5 dB/-0.5 dB) (when 10kΩ load)
• Display: 160×128 dot-matrix LCD
• Inputs L/R: Standard mono phone jacks Rated input level: −20 dBu — Input impedance (line): 470 kΩ
• Outputs L/R: Standard mono phone jacks Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher)
• Input S/N: 122 dB
